Model

Voltage
(V)

Power
(W)

Fan Blade Dia.(mm)

Encloser Dia.(mm)

Fan Diemension(mm)

R.P.M.
(r/min)

Air Volume
（m3/min）

Weights
(kg)

Recommended area
(m3)

10”(4-speed)

220V-240V~
50/60Hz

50

230

300

330*150*310

800

45.2

2.6

6

12”(3 speed/4 speed)

220V-240V~
50/60Hz

50

300

350

410*190*390

1300

62.6

3.6

10

14”(3 speed/4 speed)

220V-240V~
50/60Hz

75

350

400

450*200*430

1300

87.9

4.3

15

16”(3 speed/4 speed)

220V-240V~
50/60Hz

130

400

450

525*210*490

1300

142.8

5.8

25

18”(3 speed/4 speed)

220V-240V~
50/60Hz

145

450

500

570*210*540

1300

169.0

6.7

40

20”(3 speed/4 speed)

220V-240V~
50/60Hz

165

500

550

620*220*590

1300

191.0

7.4

50

Note: the above parameters as design parameters, and if the real size discrepancy,
in order to prevail in kind.
